- High-performance Motor and Gear System: Equipped with a coreless motor and metal gears, delivering high torque (2.5kg.cm @ 6V, 3.5kg.cm @ 7.4V) and low no-load current (140mA @ 6V, 180mA @ 7.4V).
- High-precision Control: Features a 12-bit magnetic encoder for 360° absolute position control with 0.088° resolution, supporting multiple operating modes.
- Feedback: Provides comprehensive feedback on load, position, speed, input voltage, current, and temperature.
- Electronic Protection: Includes overload, overvoltage, and overheat protection to ensure reliable operation.
- Flexible Communication and Interface: Supports half-duplex asynchronous serial communication (38400bps to 1Mbps) with customizable baud rates and IDs, using a PH1.25-3P interface.
Product | Feetech HL-3615-C002 6V 2.5Kg Servo | ||
Dimensions | 34×20×23 mm | ||
Weight | 35.8±2 g | ||
Voltage Range | 5V-8.4V | ||
Operating Voltage | 6V (Standard) | 7.4V (High Voltage) | |
No-Load Speed | 0.034 sec/60° (290RPM) | 0.027 sec/60° (365RPM) | |
Stall Torque | 2.5kg.cm | 3.5kg.cm | |
Rated Load | 0.8kg.cm | 1.2kg.cm | |
Operating Temperature | -20℃～60℃ | ||
HL-3615-C002 | x1 |
M2*4 | x8 |
15cm -1.25mm to 5264 terminal wire | x1 |
20cm -1.25mm terminal wire | x1 |
| HSCODE | 8501109990 |
| USHSCODE | 8501106080 |
| UPC | |
| EUHSCODE | 8501109390 |
| COO | CHINA |
